Iseki TF23F Specifications
The Iseki TF23F is a versatile compact utility tractor from the Sial Series, offering increased power and capability compared to earlier TF models. Powered by a 1.4L 3-cylinder diesel engine and equipped with 4WD, a 9-speed transmission, and multiple specialized variants (utility, high-crop, and narrow), the TF23F is suitable for a wide range of agricultural applications including vegetable farming, orchards, tillage, mowing, and greenhouse work.
Overview
| Item | Details |
|---|---|
| Model | Iseki TF23F |
| Type | Compact Utility Tractor |
| Series | Sial Series |
| Production Years | 1995 – ? |
| Manufacturer | Iseki |
| Drive | Four-wheel drive |
| Variants | TF23F-U (utility), TF23HF (high-crop), TF23NF (narrow) |
| ROPS | Two-post ROPS with canopy (cab optional); TF23NF includes folding ROPS |
| Engine Power | 22.7 hp (16.9 kW) |
| PTO Power (claimed) | 20.4 hp (15.2 kW) |
Engine
| Item | Details |
|---|---|
| Engine Model | Iseki 1.4L 3-cylinder diesel |
| Displacement | 1.4 liters |
| Fuel Type | Diesel |
| Fuel Tank | 6.3 gal (23.8 L) |
| Cooling System | Liquid-cooled |
| Engine Power | 22.7 hp (16.9 kW) |
Model Description (Engine):
The 1.4L diesel engine in the TF23F delivers strong torque and stable performance, particularly effective for rotary tilling, plowing, and hauling. Compared to the TF21F, the TF23F offers improved output, making it ideal for medium-intensity farm operations while maintaining high fuel efficiency.
Transmission
| Item | Details |
|---|---|
| Type | 9-speed transmission |
| Notes | Allows smooth speed selection for field work and transport |
Power Take-Off (PTO)
| Item | Details |
|---|---|
| Rear PTO Type | 540 rpm (1.375 spline) |
| PTO Speeds | 524 rpm @ 2500 engine rpm 730 rpm @ 2500 engine rpm 1269 rpm @ 2500 engine rpm |
Dimensions & Tires
| Item | Details |
|---|---|
| Wheelbase | 59.8 in (151 cm) |
| Weight | 1940 lb (879 kg) |
| Front Tire | 7-14 |
| Rear Tire | 9.5-24 |
Electrical
| Item | Details |
|---|---|
| Ground | Negative |
| Battery Voltage | 12V |
| Battery Capacity | 55 AH |
Photos
