Ford 6530 Tractor Specifications & Model Overview
The Ford 6530 is a high-clearance agricultural tractor produced from 1992 to 1996.
Built in Italy, this tractor is designed for operations that require additional crop clearance—such as vegetable farming, sugarcane, orchard rows, and tall-row cultivation.
Part of the 5530–6530–7530 high-clearance lineup, the Ford 6530 sits in the middle of the series, delivering a balance of horsepower, lifting capacity, and maneuverability.
A key feature is its Fiat-built 3.9L four-cylinder diesel engine, offering reliable torque and fuel efficiency.
With two transmission options, independent PTO, and ROPS safety structure, the Ford 6530 is a durable machine trusted by farmers worldwide.
1. Overview
| Item | Details |
|---|---|
| Model | Ford 6530 |
| Production Years | 1992–1996 |
| Type | High-Clearance Tractor |
| Manufacturer | Ford |
| Build Location | Italy |
| Original Price (1997) | USD $30,000 |
| Drive Options | 2WD or 4WD |
| ROPS | Four-post ROPS |
| Estimated Engine Power | 77.8 hp (Factory comparison estimate) |
2. Engine
The Ford 6530 is powered by a Fiat 3.9L 4-cylinder diesel engine, known for long-term durability, easy servicing, and stable fuel economy.
This engine offers dependable torque for field implements, PTO-driven machinery, and transport tasks.
| Specification | Details |
|---|---|
| Engine Model | Fiat diesel |
| Engine Type | 4-cyl, liquid-cooled diesel |
| Displacement | 3.9 liters |
| Fuel Tank Capacity | 19.3 gal (73.1 L) |
| PTO Horsepower (claimed) | 70 hp (52.2 kW) |
| Cooling System | Liquid cooled |
| Design Notes | Simple, reliable mechanical fuel system |
3. Transmission
The Ford 6530 offers two transmission choices, allowing operators to select the setup best suited for row-crop or transport work.
| Transmission | Details |
|---|---|
| 12-speed partially synchronized | Durable field gearbox with synchronized shifting in select gears |
| 20-speed synchromesh | Smooth shifting, better road speed, improved operator comfort |
| Brakes | Disc brakes |
| Final Drive | 2WD or 4WD options |
4. Hydraulics & Hitch
| Category | Details |
|---|---|
| Hydraulic Type | Open center |
| Valves | 1 to 3 |
| Pump Flow | 11 gpm (41.6 L/min) |
| Rear Hitch Type | Category II |
| Rear Lift Capacity | 5,194 lbs (2,355 kg) |
The open-center hydraulic system ensures consistent flow for implements such as sprayers, cultivators, and lifting equipment.
5. PTO (Power Take-Off)
| Specification | Details |
|---|---|
| Rear PTO | Independent |
| PTO Speeds | 540 / 1000 rpm |
| Control | Independent engagement for smoother operation |
6. Dimensions & Weight
| Specification | 2WD | 4WD |
|---|---|---|
| Wheelbase | 82.8 in (210 cm) | 80.7 in (204 cm) |
| Approx. Weight | 5,800–7,400 lbs | 5,800–7,400 lbs |
| Tires | Size |
|---|---|
| Front Tire (2WD) | 7.50×18 |
| Rear Tire (2WD) | 9.50×42 |
7. Electrical System
| Item | Details |
|---|---|
| Ground | Negative |
| Charging System | Alternator |
| Charging Output | 33 amps |
| Battery Voltage | 12V |
8. Photos
Summary
The Ford 6530 remains a highly valued high-clearance tractor due to its:
-
Dependable Fiat 3.9L diesel engine
-
Strong PTO performance at 70 hp
-
Robust hydraulics and Category II hitch
-
Flexible 12-speed or 20-speed transmission options
-
Versatile 2WD/4WD configurations
-
Excellent visibility and crop clearance
Its simple mechanical design and durability make it a preferred choice for farmers across Africa, Asia, and Central/South America who require strong performance with low maintenance demands.
