New Holland 9680 – High-Horsepower 4WD Articulated Tractor
The New Holland 9680 is a large-frame, high-power, four-wheel-drive articulated tractor produced from 1994 to 1995 as part of the 80 Series. Built by Versatile in Winnipeg, Manitoba, Canada, this model is equipped with a massive 14.0L Cummins diesel engine delivering 350 horsepower.
Designed for heavy tillage, broad-acre farming, and tough traction work, the 9680 is known for its durable outboard planetary final drives, powerful hydraulics, and reliable transmission options suitable for demanding agricultural operations.
Overview
| Item | Details |
|---|---|
| Production years | 1994 – 1995 |
| Series | 80 Series |
| Drive | 4WD articulated |
| Distributor | New Holland |
| Manufacturer | Versatile |
| Built in | Winnipeg, Manitoba, Canada |
| Engine horsepower | 350 hp (261.0 kW) |
| PTO power (claimed) | 308 hp (229.7 kW) |
| Original price (1995) | $120,000 USD |
Engine
| Item | Specification |
|---|---|
| Manufacturer | Cummins |
| Engine model | Cummins 14.0L, 6-cylinder diesel |
| Displacement | 14.0 liters |
| Cylinders | 6 |
| Fuel type | Diesel |
| Rated PTO speed | 1000 rpm @ 2100 engine rpm |
Transmission
| Option | Description |
|---|---|
| 12-speed partially synchronized | Heavy-duty mechanical gearbox |
| 12-speed full powershift | Smooth shifting under heavy load |
| Other drivetrain features | Details |
|---|---|
| Steering | Articulated power steering |
| Final drives | Outboard planetary |
| Brakes | Hydraulic disc brakes |
| Cab | Standard with air-conditioning |
Hydraulics
| Item | Specification |
|---|---|
| Type | Closed center, load-sensing |
| Hydraulic capacity | 15.3 gal (57.9 L) |
| Pump flow | 30 gpm (113.6 L/min) |
| Steering flow | 30 gpm (113.6 L/min) |
| System pressure | 2500 psi (172.4 bar) |
| Valves | Noted for strong compatibility with tillage equipment |
Capacity
| Item | Specification |
|---|---|
| Fuel tank | 245 gal (927.3 L) |
| Hydraulic system | 15.3 gal (57.9 L) |
Tractor Hitch & PTO
| Item | Specification |
|---|---|
| Rear hitch type | Category IVN |
| Hitch control | Electronic position control |
| Rear lift (24”/610 mm) | 13,036 lbs (5,913 kg) |
| Rear PTO | Independent |
| PTO type | 1000 rpm (1.75 inch shaft) |
| Engine rpm for PTO | 1000 @ 2100 |
Dimensions & Tires
| Item | Details |
|---|---|
| Wheelbase | 133.1 in (338 cm) |
| Operating weight | 25,198 lbs (11,429 kg) |
| Front tires | 20.8×38 |
| Rear tires | 20.8×38 |
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Charging system | Alternator |
| Charging output | 130 amps |
| Batteries | 3 × 12V |
| Battery CCA | 950 |
| Battery group | 31 |
