The Iseki T9520 is a robust utility tractor from the Landmax T20 Series, produced between 1990 and 1995. Designed for farmers who demand high horsepower and durability, this model combines Japanese engineering excellence with powerful Isuzu performance. With its heavy-duty build, the T9520 is ideal for large-scale farming, tilling, and transport operations, offering both strength and reliability in the most challenging agricultural environments.
| Model | Iseki T9520 |
|---|---|
| Manufacturer | Iseki & Co., Ltd. |
| Production Years | 1990 – 1995 |
| Series | Landmax T20 Series |
| Type | Utility Tractor |
| Horsepower | 93.7 HP (69.9 kW) |
| Drive System | 2WD / 4WD |
| Made in | Japan |
The Iseki T9520 stands out among Japanese heavy-duty tractors for its balance of power, comfort, and precision, making it a top choice for farmers worldwide.
Engine
The T9520 is powered by a 5.4L 6-cylinder Isuzu diesel engine, well known for its smooth power delivery and long-term reliability. This engine delivers consistent output under continuous heavy workloads, ensuring high efficiency and reduced fuel consumption.
| Engine Manufacturer | Isuzu |
|---|---|
| Type | 4-cycle, 6-cylinder diesel |
| Displacement | 5.4 liters |
| Gross Power | 93.7 HP (69.9 kW) |
| Cooling System | Water-cooled |
| Fuel System | Direct injection |
Thanks to the Isuzu engine, the Iseki T9520 performs excellently under various agricultural conditions—from plowing and planting to hauling and field preparation.
Transmission
The tractor offers two transmission options, giving operators the flexibility to match performance with workload demands.
| Transmission Type | 12-speed Synchromesh / 24-speed Creeper |
|---|---|
| Clutch | Hydraulic wet disc |
| Drive | 2WD or 4WD |
| Steering | Power steering |
| Brakes | Wet disc brakes |
The synchromesh gearbox allows for smooth and effortless gear shifting, while the creeper option supports extremely low speeds, making it perfect for precision work such as planting and spraying.
Performance & Power
| Engine Power | 93.7 HP (69.9 kW) |
| PTO Type | Independent |
| PTO Speeds | 540 / 1000 RPM |
| PTO Clutch | Hydraulic wet disc |
With nearly 94 horsepower, the Iseki T9520 provides excellent traction and torque, easily powering heavy implements such as plows, rotavators, and trailers.
Hydraulics & Hitch
The Iseki T9520’s Category II rear hitch supports a wide range of heavy-duty implements, enhancing farm efficiency and versatility.
| Rear Hitch Type | Category II |
| Lift Control | Position control |
| Hydraulic System | Open center |
This setup ensures stable performance and accurate control for large agricultural equipment.
Dimensions & Tires
| Wheelbase | Approx. 220 cm |
| Weight | Around 3,000–3,500 kg (varies by configuration) |
| Front Tires | 9.5-20 |
| Rear Tires | 18.4-34 |
The wide stance and balanced design of the T9520 give it excellent stability and traction even on uneven terrain, making it suitable for both dry and wet farming conditions.
Electrical System
| Ground | Negative |
| Battery Voltage | 12V |
This reliable electrical setup ensures quick starting and dependable operation in any climate.
Operator Comfort & Design
The Iseki T9520 was built for operator comfort and long working hours. It features a spacious platform, ergonomic controls, and optional cab for better protection from dust and weather. The four-post ROPS (Roll-Over Protective Structure) enhances safety while maintaining visibility in the field.
Why Choose the Iseki T9520?
The Iseki T9520 combines the reliability of Japanese technology with the strength of a 6-cylinder Isuzu diesel engine. It’s designed for professionals who need a dependable, high-power utility tractor for a wide range of agricultural applications.
Key Advantages:
✅ Strong 93.7HP Isuzu diesel engine
✅ Smooth 12-speed or 24-speed transmission
✅ 2WD/4WD flexibility
✅ Excellent hydraulic performance
✅ Comfortable operation for long hours
With its impressive specifications and global service reputation, the Iseki T9520 remains a trusted workhorse for farms worldwide.
